Pipe made in Black AS1163 C250LO Grade C250 Pipe, for general mechanical and low pressure reticulation applications, is manufactured by cold-forming and high frequency Electric Resistance Welding. The cold-forming process enhances the strength, hardness and surface finish of the pipe and produces product to tight dimensional tolerances

0.0 (0 Reviews)

0 Sold

$35.88

Received successfully

Coupon Code

CONTINUE SHOPPING

Please select the information you want X

SIZE:

15MM*2.6MM

20MM*2.6MM

25MM*3.2MM

32MM*3.2MM

40MM*3.2MM

50MM*3.6MM

65MM*3.6MM

80MM*4.0MM

90MM*4.0MM

100MM*4.5MM

125MM*5.0MM

150MM*5.0MM

Quantity:

Add to Favorites (0)

1/1

Description

DESCRIPTION	OD(MM)	WT(MM)	ID(MM)	DN(MM)	KG/MT	NB(INCH)
Midium galvanised pipe 15MM*2.6MM AS1163 C250 LO	21.3	2.6	16.1	15	1.26	1/2"
Midium galvanised pipe 20MM*2.6MM AS1163 C250 LO	26.9	2.6	21.7	20	1.63	3/4"
Midium galvanised pipe 25MM*3.2MM AS1163 C250 LO	33.7	3.2	27.3	25	2.51	1"
Midium galvanised pipe 32MM*3.2MM AS1163 C250 LO	42.4	3.2	36	32	3.22	1-1/4"
Midium galvanised pipe 40MM*3.2MM AS1163 C250 LO	48.3	3.2	41.9	40	3.64	1-1/2"
Midium galvanised pipe 50MM*3.6MM AS1163 C250 LO	60.3	3.6	53.1	50	5.21	2"
Midium galvanised pipe 65MM*3.6MM AS1163 C250 LO	76.1	3.6	68.9	65	6.56	2-1/2"
Midium galvanised pipe 80MM*4.0MM AS1163 C250 LO	88.9	4	80.9	80	8.62	3"
Midium galvanised pipe 90MM*4.0MM AS1163 C250 LO	101.6	4	93.6	90	9.63	3-1/2"
Midium galvanised pipe 100MM*4.5MM AS1163 C250 LO	114.3	4.5	105.3	100	12.5	4"
Midium galvanised pipe 125MM*5.0MM AS1163 C250 LO	139.7	5	130.7	125	16.7	5"
Midium galvanised pipe 150MM*5.0MM AS1163 C250 LO	165.1	5	155.1	150	19.9	6"
